0.6" Textile Dome Tweeter

ASDDT1000-0400

Feature
0.6", Plastic Frame
Textile Dome Diaphragm
Neodymium Magnet Motor System
Water Proof Speakers IPX7
Low Distortion (<3%)
Size
0.60 Inch
Fs
1780.0 Hz
Re
4 Ohms
Sensitivity
86.00 dB
Quality Factor
1.921 Qts
Rated Power
10 W
  • Description
  • Simulation
  • Measure Chart
  • Specification
  • Mechanical Drawing
SPEC SHEET

This compact tweeter features a 4ohm 0.6 inch voice coil, a textile dome diaphragm and neodymium magnet. This tweeter uses CCAW, which further extend the high frequency response and is up to the standard of IPX7. The clever design of a circular frame is easy to install into customized faceplates.

Family
Range
ASDDT1000-0400

T-S Parameters
Resonance frequency [fs] 1780 Hz
Mechanical Q factor [Qms] 5.143
Electrical Q factor [Qes] 3.065
Total Q factor [Qts]  1.921
Force factor [Bl] 1.387 Tm
Mechanical resistance [Rms] 0.284 kg/s
Moving mass [Mms]  0.131 g
Compliance [Cms] 0.061 mm/N
Effective diaph. diameter [D]  18 mm
Effective piston area [Sd] 2.54 cm²
Equivalent volume [Vas] 0.0006 l
Sensitivity (2.83V/1m)  86 dB
Ratio Bl/√Re 0.69 N/√W
Ratio fs/Qts 926.6 Hz
Electrical Data
Nominal impedance [Zn]  4 Ω
Minimum impedance [Zmin]  4.1 Ω
Maximum impedance [Zo] 9.69 Ω
DC resistance [Re] 4.03 Ω
Voice coil inductance [Le]  0.028 mH
Power Handling
100h RMS noise test (IEC 17.1) 10 W
Long-term max power (IEC 17.3) - W
Voice Coil & Magnet Data
Voice coil diameter 16.4 mm
Voice coil height 2 mm
Voice coil layers 2
Height of gap 2 mm
Linear excursion ± - mm
Max mech. excursion ± - mm
Unit weight 0.022 kg
