ASDCT2000-0600
ASDCT2000-0600
Standard Transducers
Tweeter

ASDCT2000-0600

Feature
2",Steel Frame
0.5",PECCAW Voice Coil,Kapton Former
PaperDiaphragm,PU Surround
Ferrite Magnet Motor System
Size
2.0 Inch
Fs
1585.0 Hz
Re
6 Ohms
Sensitivity
90.00 dB
Quality Factor
1.010 Qts
Rated Power
20 W
  • Description
  • Measure Chart
  • Specification
  • Mechanical Drawing
SPEC SHEET

This is a 2 inch 6ohm transducer, it is a tweeter features 0.5inch voice coil with CCAW. In term of suspension system, cone is consisted by Paper Cone body with fixed surround and spider is consisted by Conex. In term of magnetic motor system, magnet is consisted by Ferrite material.

Range

T-S Parameters
Resonance frequency [fs] 1585 Hz
Mechanical Q factor [Qms] 1.25
Electrical Q factor [Qes] 6.1
Total Q factor [Qts]  1.01
Force factor [Bl] 1.95 Tm
Mechanical resistance [Rms] 3.22 kg/s
Moving mass [Mms]  0.4 g
Compliance [Cms] 0.03 mm/N
Effective diaph. diameter [D]  39 mm
Effective piston area [Sd] 11.95 cm²
Equivalent volume [Vas] 0.005 l
Sensitivity (2.83V/1m)  90 dB
Ratio Bl/√Re 0.34 N/√W
Ratio fs/Qts 1569 Hz
Electrical Data
Nominal impedance [Zn]  6 Ω
Minimum impedance [Zmin]  5.33 Ω
Maximum impedance [Zo] 6.41 Ω
DC resistance [Re] 5.64 Ω
Voice coil inductance [Le]  0.05 mH
Power Handling
100h RMS noise test (IEC 17.1) 20 W
Long-term max power (IEC 17.3)      W
Voice Coil & Magnet Data
Voice coil diameter 13.28 mm
Voice coil height 2.7 mm
Voice coil layers 2
Height of gap 2.5 mm
Linear excursion ± 0.1 mm
Max mech. excursion ± - mm
Unit weight 0.141 kg



ASDCT2000-0600
