Standard Transducers
Fullrange

02A13EHC19173

Feature
0.87”, Plastic Frame
0.56” CCAW Voice Coil, Aluminum Former
Titanium Dome with Polyurethane Surround
Neodymium Magnet Motor System
Frequency Response Extended to 10 kHz
Spider-less
Size
0.9 Inch
Fs
468.7 Hz
Re
4 Ohms
Sensitivity
80.50 dB
Quality Factor
0.480 Qts
Rated Power
1 W
  • Description
  • Measure Chart
  • Specification
  • Mechanical Drawing
SPEC SHEET

This compact full-range speaker features a 0.56 inch voice coil, Titanium dome diaphragm with Neodymium Magnet for high SPL. The full-range speaker also features CCAW, which can extend the high frequency response to 10 kHz. This product is designed for premium compact sound bars and portable speaker applications.

Range
Characteristics

T-S Parameters
Resonance frequency [fs] 468.7 Hz
Mechanical Q factor [Qms] 0.69
Electrical Q factor [Qes] 1.6
Total Q factor [Qts]  0.48
Force factor [Bl] 1.36 Tm
Mechanical resistance [Rms] 1.06 kg/s
Moving mass [Mms]  2.52 g
Compliance [Cms] 0.45 mm/N
Effective diaph. diameter [D]  18 mm
Effective piston area [Sd] 2.54 cm²
Equivalent volume [Vas] 0.0042 l
Sensitivity (2.83V/1m)  80.5 dB
Ratio Bl/√Re 0.68 N/√W
Ratio fs/Qts 966.3 Hz
Electrical Data
Nominal impedance [Zn]  4 Ω
Minimum impedance [Zmin]  3.7 Ω
Maximum impedance [Zo] 5.9 Ω
DC resistance [Re] 4 Ω
Voice coil inductance [Le]  0.036 mH
Power Handling
100h RMS noise test (IEC 17.1) 1 W
Long-term max power (IEC 17.3) 1.5 W
Voice Coil & Magnet Data
Voice coil diameter 14.28 mm
Voice coil height 1.4 mm
Voice coil layers 4
Height of gap 1 mm
Linear excursion ± 0.2 mm
Max mech. excursion ± - mm
Unit weight 0.0137 kg
